Type Y31800B

Max.workpiece diameter(with rear colum/no rear column) no column   value="8000" tcsc="0" unitname="mm" w:st="on">8000mm

                                              have column

Min.workpiece diameter       value="1400" tcsc="0" unitname="mm" w:st="on">1400mm

Max.working width    value="1800" tcsc="0" unitname="mm" w:st="on">1800mm

Max.spiral angle     45

Max.hobbing module Hob steel    30

                      cast iron    40

                   Finger-type milling cutter steel    50

                                        cast iron    65

                   Wafer milling cutter steel    40

                                    cast iron    value="55" tcsc="0" unitname="mm" w:st="on">55mm

Max.hob dimension Outer diameter    value="400" tcsc="0" unitname="mm" w:st="on">400mm

Length    value="500" tcsc="0" unitname="mm" w:st="on">500mm

Tool post vertical stroke    value="1800" tcsc="0" unitname="mm" w:st="on">1800mm

distance from hob center to worktable center Max     value="4250" tcsc="0" unitname="mm" w:st="on">4250mm

                                     Min      700

Hob rotate speed     5.5value="40" tcsc="0" unitname="mm" w:st="on">-40mm

Worktable diameter    3730

Feeding capacity Hobbing vertical    0.23-4.6

                      level      0.43-8.6

                      single(finger type tool post)    0.066-1.316

Fast speed Slide base   63-157

         Column    117-292

         Automatic cutter withdrawal   57

Worktable loading capacity   65

Machine total power   45kw

Machine overall dimension Length   value="13810" tcsc="0" unitname="mm" w:st="on">13810mm

                          Width     value="5070" tcsc="0" unitname="mm" w:st="on">5070mm

                          Height   value="5200" tcsc="0" unitname="mm" w:st="on">5200mm

Machine weight(about)  131

FOB Dalian US$987525
