Type 31500B

Max.workpiece diameter(with rear colum/no rear column) no column   value="5000" tcsc="0" unitname="mm" w:st="on">5000mm

                                              have column

Min.workpiece diameter   value="1400" tcsc="0" unitname="mm" w:st="on">1400mm

Max.working width   value="1800" tcsc="0" unitname="mm" w:st="on">1800mm

Max.spiral angle   45

Max.hobbing module Hob steel    30

                      cast iron   40

                   Finger-type milling cutter steel  50

                                        cast iron  65

                   Wafer milling cutter steel  40

                                    cast iron  value="55" tcsc="0" unitname="mm" w:st="on">55mm

Max.hob dimension Outer diameter   value="400" tcsc="0" unitname="mm" w:st="on">400mm

Length  value="500" tcsc="0" unitname="mm" w:st="on">500mm

Tool post vertical stroke   value="1800" tcsc="0" unitname="mm" w:st="on">1800mm

distance from hob center to worktable center Max   value="2950" tcsc="0" unitname="mm" w:st="on">2950mm

                                     Min   700

Hob rotate speed  5.5value="40" tcsc="0" unitname="mm" w:st="on">-40mm

Worktable diameter  3730

Feeding capacity Hobbing vertical  0.23-4.6

                      level   0.43-8.6

                      single(finger type tool post )  0.066-1.316

Fast speed Slide base  63-157

         Column  117-292

         Automatic cutter withdrawal  57

Worktable loading capacity  65

Machine total power  45kw

Machine overall dimension Length  value="13810" tcsc="0" unitname="mm" w:st="on">13810mm

                          Width  value="5070" tcsc="0" unitname="mm" w:st="on">5070mm

                          Height  value="5200" tcsc="0" unitname="mm" w:st="on">5200mm

Machine weight(about)   109
