This high effecient equipment was made for professional manufacturer of personality cards . It is low wastage rate ,easy to operate effectively. As the professional smart card automatic laminator(Smart card making equipment ) it also can satisfy the PVC card company and PVC card factory enough to produce the second generation identification cards and top quality certificate cards,banking cards,one card solution for bus,high way,social insurance card and so on. It is good enough for 8K,16K offset printing machine users .

Technical parameter:

Smart card automatic laminator(Smart card making equipment)

Model :WL-FA3000 PLC

Power Supply:       380V　50HZ

Power :14KW

Pressure method:       Hydraulic

Pressure steps:       Heating :5 steps ,cooling :1 step

Controlling method:   PLC

Pressure bound :       0-16 mpa　　precision:±1mpa

Temperature bound:    0-200　Precision:±2

Time bound: 0-9000 Seconds  Precision:±1Second

Laminating area:       210mm*297mm

Production speed:     more than 2000cards/hour

Laminating layers:     Five heating and five cooling

Cooling method:       Water cycling

Heating method:       imported electric heating element

Outline dimension:        L1780mm*W510mm*H1480mm

Weight:  1500kg
