Brand:Henan Dafu
Model:Y200L1-6
MOQ:1 Sets
Dryer is used for drying materials with a certain humidity or granularity in milling of ores, building matrials, metallurgy and chemical industry. Gyro drying machinery has a strong adaptability of materials and it can dry various materials. The operation is very simple and liable. For this reason ,it is used widely.
| Items | Inside diameter of outer shell | Inside diameter of inner shell | Shell length | Shell cubage | Shell | Lifting blade | Highest inlet air | Dimensions |
| Shell diameter *shell length | mm | mm | m | m3 | Obli-quity | form | Tem.oC | |
| Ø1.5*15m | 1500 | 500 | 15 | 20.27 | 3-5% | Lifting form | 850 | 16.2*2.7*2.7 |
| Ø1.5*17m | 17 | 22.97 | 18.2*2.7*2.7 | |||||
| Ø1.5*19m | 19 | 25.68 | 20.0*2.9*2.9 | |||||
| Ø1.8*21m | 1800 | 650 | 21 | 35.91 | 3-5% | Lifting form | 850 | 22.5*2.7*2.7 |
| Ø1.8*23m | 23 | 39.33 | 24.5*2.9*2.9 | |||||
| Ø1.8*25m | 25 | 42.75 | 26.5*2.9*2.9 |
