Brand:weili
Model:LBW1800PB
MOQ:1 Sets
Main feature and function:
1 adopt PLC to control the working condition, touch screen and man-machine interface
2 low-e glass automatic diagnosis system
3 adopt oil water-proof bearing in the washing section
4 produce double glazing and triple glazing and shaped insulating glass
5 conserves energy interrupted type automatic operation system
6 hydraulic pressure provides power for plate press section, able be open 450mm for maintenance
7 brushes can wash coating glass, low- e glass, variable frequency drive.
8the low-voltage apparatus adopted the international famous brand.
9 having two kinds of operation model: automatic operation and manual operation
10 hydraulic system provides power for plate press section, able be open 450mm for maintenance. Linear guide rail can make front flat press section move more stable.
11 this glass panels is made of high density board, moisture and hard to distort
Technical parameter
|
Technical Parameter | LBZ1800PBVertical insulating glass automatic flat press production line | LBZ2200PB Vertical insulating glass automatic flat press production line | LBZ2500PB Vertical insulating glass automatic flat press production lin |
| Min glass size | 280*450mm | 280*450mm | 400*280mm |
| Max glass size | 1800*2500 | 2200*3000 | 2500*3000 |
| Washing glass speed | 0-8m/min
| 2-12m/min
| 2-12m/min
|
| Power supply | 380V/50HZ 28KW | 380V/50HZ 28KW | 380V/50HZ 38KW |
| Insulating max glass thickness | 40 mm
| 40 mm
| 40 mm
|
| Transmission glass speed | 45 m/min
| 45 m/min
| 45 m/min
|
| Air pressure | 1Mpa | 1Mpa | 1Mpa |
