CNC foam contour cutting machine BC1030 (Circular blade)
| Model | BC1030 |
| Dimensions(L*W*H) | 5980*4750*3020mm |
| Working table size)(L*W) | 3000*2000mm |
| Handing size(L*W*H) | 3000*2000*1200mm |
| Speed of cutter | 0.5-5m/min |
| Precision | 0.5mm |
| Weight | 3000kg |
| Power | 7KW |
△ The machine is the most advanced and fully automatic conputerised foam contour cutting machine, Can cut the various shape by computerised system.
△ 1.Operated by computer and use CAD software to design the shape for the foam blocks. Make full use of the foam blocks and extremely save the raw material(foam blocks) cost.
△ 2.The operator can monitor the whole process simultaneously and design all the data by themselves.
△ 3.Equipped with high precision servo mechanism system; Rapid cutting speed and accrurate cutting; Can enhance the working efficiency.
△ 4.No dust raise during cutting process,low noise.
△ 5.Operating system:Windows XP / Vista.
△ 6.Designing software: Auto CAD.
△ 7.Cutting software:Foam cutting control system.
