Cast Iron Pad Box

Cast Iorn Square Box with T-slot

T-slot Cast Iron Square Box

Cast Iron Square Box

Inspection Cast Iron Square Box

Cast Iron Square Cylinder

Usage: Cast iron working pad boxes are used for assembling or dynamic mechanical performance test of large-scale machines and equipments in laboratory or workshop. They are also used for fixing and clamping of workpieces while machining in machine processing workshop

SPECIFICATION:

Material: HT200-300

Standard: JB/T3411.56-99

Specification: customize

Surface: T-slots

Hardness of the working surface: HB160-240

Surface treatment: hand-scraped or finish-milling

Foundry process: sand casting or centrifugal castings

Molding type: resin sand molding

Painting: primer and face painting

Surface coating: pickling oil and plastic-lined or covered with anticorrosion paint

Working temperature: (20±5)℃

Precision grade: 2-3

Packaging: plywood box
