TNG100 Touch Interactive Whiteboard
2016-10-05 23:45  Views:270
Price:0.00 USD/-
Brand:NHBOARD
Model:TGN100
MOQ:-0 -
Send Inquiry



               Specifications of NHBoard Touch Sensitive   Whiteboard



 Model

 TGN70/TGU70

 TGN83/TGU83

 TGN100/TGU100

 TGN115/TGU115

 Physical Size

(mm)

 1390×1065×20

69 inch

 1675×1279×20

83 inch

2193×1273×20

100 inch

2525×1460×20

115 inch

 Active Size

(mm)

 1298×973

64 inch

 1608×1198

79 inch

 2101×1181

95 inch

2433×1368

110 inch

Packing Size

(mm)

1470×1145×100

1755×1359×100

2273×1353×100

2605×1540×100

Aspect Ratio

4:3

4:3

16:9

16:9

Net Weight

(KG)

20

24

33

39

 Packing Size

(KG)

25

30

40

49

Working Principle  Touch Sensitivity
Writing Way Pen, finger or other blunt objects
Board Surface  Adopts special hard-coated polyester, the surface is clear, tear proof. (Water whiteboard film is available. Use board cleaner to remove)
Interface Standard USB 2.0 Cable
Resolution  9600*9600
Calibrate Accuracy ≤1mm
Processing Speed 500 dots/second
Tracking Speed 5m/Second
Power Supply USB
Power Consumption  ≤1W
Operating System  Windows98/2000/2003/xp/vista/window7
Temperature  Working Temperature:-15-50°C  Storage Temperature:-40-50°C
Humidity  Working Humidity:20-90%  Storage Humidity:10-95%
Standard Accessories Whiteboard Pen 2 pcs, USB cable 1 pc, Wall Mounted Bracket 1 set, Driver CD (software and user guide) and User's Manual.
Optional Accessories  Mark Pens 2 pcs, Eraser 1 pc,Mobile Floor Stand, Mobile Floor Stand with Projector Mount, Wall Mounted Projector Mount
Certificates  CE, FCC, C-tick and ISO.
Warranty  3 years
