Aluminium Alloy Welding Wire

ER4043,ER5356,ER556,ER1050,ER4047,ER5183

Size: 0.8mm to 5.0mm

Description / Application

Aluminium alloy welding wire ER5356 is 5% magnesium aluminum filler metal.

The weld deposit of this filler metal offer good Corrosion resistance when exposed to salt water. This alloy is commonly used on base metals 5050, 5052,5083, 5356, 5454 and 5456.

Chemical composition (%):

Si 0.25

Fe 0.40

Cu 0.10

Mn 0.05 0.20

Mg 4.50 5.50

Zn 0.10

Ti 0.06 0.20

Cr 0.05 0.20

Spec:

MIG-0.8MM, 0.9MM, 1.0MM, 1.2MM, 1.6MM

TIG-1.6MM, 2.0MM, 2.4MM, 3.2MM, 4.0MM

Packaging:

MIG-7kg/ Spool (D300), 2kg/Spool (D200), 0.5kg/Spool (D100)

TIG-5kg/Carton, 10kg/Carton

4043 Aluminum Welding Wire

Nominal Composition:

Silicon 5. 15

Iron 0. 21

Copper 0. 02

Manganese 0. 01

Magnesium 0. 001

Zinc 0. 01

Titanium 0. 01

Beryllium 0. 000

Aluminum 94. 55

Physical Properties:

Solidus 574C / 1065F

Liquidus 632C / 1170F

Color Gray

Tensile Strength 27 000 psi

Yield Strength 18 000 psi
