Sensor: 1/2.8" Exmor CMOS

Effective Pixels Approx: 2.2 mega pixels

Lens:10 optical,12 digital

Signal System: 1080P/30 720P/25

Built-In Video Output:USB 2.0

Camera Control Interface: RS-232C/RS-422

Preset Positions: 255

Tilt Angle:  -30 to +90 degrees

Pan Angle: -170 to + 170 degrees

Tilt Speed: 0.1 to 120 degrees/sec

Focal Length: f=5.1mm-51mm,  F=1.6-2.5

Shutter Speed: 1/1 to 1/10000 Sec

Minimum Illumination：0.2 Lux /0.005 Lux

Minimum Object Distance: 10mm

S/N Ratio: 50 dB

Focus System: Auto/Manual

Image Flip： On/Off

Backlight Compensation: On/Off

Gain: Auto/Manual

Synchronization: Internal/External

Power Consumption Max: 12W

Power Requirements: DC 12 V

Operating Temperature: -10 degrees to 50 degrees

Storage Temperature: -20 degrees to 60 degrees

Dimensions: (W x H x L) 131.5 x 154 x 143mm

Weight:1.8 kg
