Sensor: 1/2.8"  Exmor CMOS

Effective Pixels Approx: 2.38 mega pixels

Lens：30 x optical zoom,12 x digital zoom

Signal System: 1080/60P,50P,1080/30P,25P,1080/60i,50i,720/50P,60P 720/30/25

Built-In Video Output: HDMI,3G-SDI,YPbPr,CVBS,DVI-I

Camera Control Interface: RS-232C/RS-422

Preset Positions: 255

Tilt Angle:  -30 to +90 degrees

Pan Angle: -170 to + 170 degrees

Tilt Speed: 0.1 to 120 degrees/sec

Focal Length: f=4.3 to 129 mm (F1.6 to F4.7)

Shutter Speed: 1/1 to 1/10000 Sec

Minimum Illumination： 0.35 lux

Minimum Object Distance: 10mm

S/N Ratio: 50 dB

Focus System: Auto/Manual

Image Flip： On/Off

Backlight Compensation: On/Off

Gain: Auto/Manual

Synchronization: Internal/External

Power Consumption Max: 12W

Power Requirements: DC 12 V

Operating Temperature: -10 degrees to 50 degrees

Storage Temperature: -20 degrees to 60 degrees

Dimensions: (W x H x L) 131.5 x 154 x 143mm

Weight 2.3 kg
