Features :

- The control panel and LCD display provides a simple interface to

adjust the machine settings. Up to eight cutting conditions can be

saved for rapid recall

- The CE5000 features a tangential control mode, enabling precise

blade rotation control, ensuring square corner cuts, without

rounded or lifted edges. This unsurpassed cutting quality is

perfect for processing intricate designs on a variety of material

- Cutting force is programmable: the 24" CE5000-60 has a 31-step

range up to 300g

- ROBO Master Pro and Cutting Master 2 Software Included - Windows

and Mac OS X Compatible

- USB 2.0 (1.1 backward compatible) and RS232C ports connect with

virtually any computer

- The precisely crafted media supply system, as an integrated part

of the floor stand (standard for both CE5000-60 & the CE5000-120),

ensures accurate loading of media material and makes demanding

long-length tracking and repetitive job operations effortless

- The CE5000's media tracking capability is further enhanced when

the optional media catch basket is utilized as another integrated

part of its floor stand

- The Auto Pre-Feed function automatically unwinds and pre-feeds

roll media as neede This feature enhances the plotter's tracking

capability and is useful for unattended repeat jobs and long-length

projects

- With Auto Pre-Feed active, the CE5000 advances the media to a

user-specified distance, upon recognition of plot data exceeding

the pre-fed length

Specifications :

CPU: 32-bit CPU
Configuration: Microgrit Rollers, moving media
Drive system: Digital Servo Motor
Maximum cutting area: 47.8 in x 164 ft (1213 mm x 50 m)
Assured Accuracy: 47.0 in x 16.4 ft (1194 mm x 5 m)

Compatible Media widths: Min: 3.3 in (85 mm) Max: 53 in (1346 mm)

Maximum Media thickness: 10 mils (0.25 mm)
Maximum Cutting speed: 40 in/s (100 cm/s) @ 45° angles
Cutting Speeds: 1-10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60 cm/s
Cutting Force: 0.2-4.4N (20 gf to 450 gf) (38 levels)
Minimum character size: Approx. 20 point, 0.196 inches (5 mm) for

alphanumeric characters (depends on the medium, font, etc.)
Mechanical resolution: 0.0002 in (0.005 mm)
Programmable resolution: GP-GL: 0.01, 0.025, 0.05, 0.1 mm HP-GL:

0.025 mm
No. of Tools mountable: 1 - blade or pen
Compatible Cutter type: Graphtec SuperSteel blades, 0.9mm and 1.5mm

diameter.
Compatible Pen type: Graphtec Water-based fiber-tip pens
Compatible Media: Vinyl film, fluorescent, decal, light reflective

(except high-luminosity), paint masking, banner, thermal transfer

vinyl, flex, flock, image transfer media, vinyl print media
Interface: Serial RS-232C / USB 2.0 High Speed
Data Buffer: 2 MB
Command modes: GP-GL, HP-GL
Display panel: Liquid Crystal Display (16 characters x 1 row)
Power Supply Input: 100 to 240 VAC, 50/60 Hz 1.2A
Power Consumption: 100 VA
Operating Environment: 50 - 95 deg. F (10 - 35 deg. C), 35 - 75% RH

(non-condensing)
Operating Environment: 61 - 80 deg.F (16 - 32 deg.C) 35 - 70% RH

(non-condensing)
Dimensions w/ stand (W x D x H): 58.5 x 29.3 x 47.0 in / 1487 x 744

x 1194 mm
Equipment Weight w/ stand: 88 lbs / 40 kg

Item Includes :

- Graphtec CE5000 48-inch Wide E-Class Cutter
- Sturdy Floor Stand
- Roll Media Bracket
- ROBO Master Software
- Cutting Master Plug-In
- Graphtec Warranty
