Features

-Highest cutting force in its class: 600gf maximum cutting force

for cutting wider variety of materials

-Fastest cutting speed in its class: 1485mm/s maximum cutting speed

for the higher productivity

-Reliable long-length tracking capability: The 3 step push roller

provides a more stable long length cutting for 15m (50feet)

tracking guarantee for cutting wider range of materials

-3 inch LCD operation panel: 3 inch LCD display with interactive

operation and icon menu enables easy-to-use key operation. Further

more, plotter conditions are displayed by icons, so the setting

conditions can be checked without key operations

-ARMS4.0: Advanced Registration Mark Sensing system for improved

handling

-By memorizing the sensor's pre-read numbers on media and

registration mark, ARMS4.0 can read registration marks in colored

background

-Four-point registration mark sensing and X/Y-axis correction uses

high-precision positioning to ensure accurate cutting of graphics

that have been distorted during the printing and laminating process
-The intermediate registration marks in the media feed direction

are detected to allow four-point correction for each individual

segment area. This enables high-precision positioning of the whole

area of skewed prints produced using long-length printing

-Layout instructions are sent together with the cutting data for

designs printed using layout functions such as set in a RIP,

enabling continuous detection of registration marks for cutting.

This feature is valuable when high accuracy is needed for cutting

an array of copies

-The first registration mark is detected automatically, eliminating

the need to move the sensor to the registration mark manually.

Subsequent registration marks are automatically redetected even if

sensing errors occur, simplifying the process of registration mark

sensing

-Supports registration mark commands: Registration mark commands

are provided to control ARMS functions from a PC. Registration mark

data including size and spacing can be controlled to simplify

operations

-Cutting Plotter Controller: Using the controller, plotter

operation and setting can be executed from PC. The tool condition

which is set by controller can list up to 100 subjects, the

contents of the list can be saved in PC as a file or can be read

-Cutting Master 2: This plug-in software allows direct cutting from

Adobe Illustrator and Corel Draw. Create graphics or text, then

output directly to the plotter

-Bi-directional media loading: For the ultimate convenience and

versatility, users now have the option to load media from either

the front or back of the FC8000, depending on location and

requirements of the plotter

-Application for Garment: The FC8000 series can be used for the

Apparel market, in pattern making and marking
-Light point: The light pointer provides an alternative to the

automatic ARMS system, allowing users to manually detect

registration marks

-Automatic cross cutter: The automatic cross cutter provides a

simple solution for obtaining a straight sheet cut-off of your

finished job

-Media supply mechanism: The media supply mechanism assists users

to load and align the media accurately

-Sophisticated tangential control algorithms: When the Tangential

Control mode is engaged, the FC8000 over-cuts the mechanical

tangential system both in speed and output quality by controlling

the blade rotation

-The on-board tool height sensor detects the blade tip's landing on

the media surface, then intelligently and precisely aligns the

blade rotation for the following cutting operation, all in a

fraction of a microsecond

-Improved cutting/plotting quality and prolonged tool life are just

a few of the outstanding standard features you can expect from the

FC8000 series, made possible by the innovative Intelligent Soft

Landing Tool

-The Graphtec proprietary closed-loop servo actuator, with an

integrated precision sensor, ensures quick precise, yet gentle tool

contact with the material surface during up and down motions. The

Soft landing features prolongs the life of the cutting/plotting

tool and maximize throughput performance

-The innovative Intelligent Soft Landing Tool provides not only

consistent and optimum cutting quality throughout the job but the

benefit of Lower operating cost as well

Specifications :

CPU: 32-Bit
Configuration: Digital Servo Friction feed with MicroGritroll drive
Max. cut width (expanded mode) : 610 mm (24 in)
Mountable media: max. width : 770 mm (30.3 in)
Mountable media: min. width : 50 mm (2 in)
Max. cross cut area: 734 mm (28.9 in)
Max. cutting speed (Axial): 1485 mm / sec (58.5 in/s) at a 45deg.

angle
Max. axial acceleration: 4.0 G (39.2 m/s2)
Cutting pressure: 20 g to 600 g (0.196 N to 5.88 N) in 48 steps
Min. character size: 3 mm (0.125 in) alphanumeric Helvetica med.

Font
Mechanical resolution: 0.005 mm (0.0002 in)
Programmable resolution: GP-GL: 0.1 / 0.05 / 0.025 / 0.01 mm, HP-

GL: 0.025 mm
Repeatability: Max. 0.1 mm / 2 m (0.0039 in / 80in)
Tools: Accepts (1) cutting blade, (1) plotting pen, or (1) pouncing

tool
Pen types: Water-based fiber-tip, oil-based ballpoint and

disposable ink pens
Pouncing tool type: Requires optional pouncing tool: (PPA33-TP12,

1.2-mm pin diameter)
Media types: Self-adhesive vinyl film, diamond grade, fluorescent

film, reflective film, Amberlith, Rubylith, window film, high-

intensity reflective film, paint protection film, up to 0.25 mm

tick, sandblast resist rubber up to 1 mm thick
Compatible paper for pouncing: Regular paper from 0.06 to 0.13 mm

thick
Standard interfaces: RS-232C / USB2.0 (Full speed) Option: Ethernet

(10 base-T / 100 base-TX)
Buffer memory: 2 MB
Command sets: GP-GL / HP-GLTM
LCD display Graphic type: 3 inches LCD backlight type
Power supply: 100 to 240 VAC/50 to 60 Hz (Auto switching)
Power consumption: 160 VA max.

Operating environment:
-Temperature: +10 to +35 deg.C
-Humidity: 35 % to 75 % (non-condensing)

Guaranteed accuracy environment:
-Temperature: +16 to +32 deg.C
-Humidity: 35 % to 70 % (non-condensing)

External dimensions (W x D x H): 1128 x 715 x 1219 mm / 44.4 x 28.1

x 48 in (including stand)
Weight including stand: 38 kg / 83.8 lbs (including stan
