Brand:Shengbao
Model:-
MOQ:-0 -
Send Inquiry
Class 200 copper winding enameled wire detail information:
| Products | EI/AIW 180 copper wires |
| Size Range | 0.10-4.0mm |
| Insulation | Polyesterimide / polyamide-imide |
| Thickness of insulation film | 0.1. 2 EI/AIW G1 G2 G3 |
| Conductor | Copper |
| Products Standard | JIS IEC NEMA GB |
| Thermal Class | C /200 ℃ |
| Wrapping | Different spools according to wires size + cartons + pallet, or upon customizing. |
| Production capacity | 30000 metric tons per year |
| Product certifications | ISO9001-2008, ISO14001-2004, OHSAS18001-2007, TUV, UL( No. E194766) |
Class 200 copper winding enameled wire merit:
Very high thermal properties and high chemical properties; standing ware and tear and excellent coolant resistance, suitable for high speed automatic whirling.
Class 200 copper winding enameled wire application:
For electrical machines with heat-resistance and anti-explosion properties, transformers, electric apparatus and electromagnetic valves with heat resistance, also widely used in harsh environment and suitable for high speed electrical machine producing high temperature, on and off frequently and for coils of electrical machines sealed up.
