Brand:fucheng
Model:FPSC-1
MOQ:-0 -
Send Inquiry
Main Technical Parameters
| Impacting ability: 1275J | Rod Diameter :85mm |
| Percussive Frequency:480-780/min | Speed:0-15km/h |
| Hydraulic Flow Rate:45-85L/min | Max. traction: 95KN |
| MIN turning radius:2350mm | Mini. Ground Clearance:195mm |
| Climbing Ability: 13° | Dimension: 6600*1300*1950 |
| Weight: 7.5T | Engine: F6L912W 63KW /2300r/min |
| Hydraulic pump: PV22 | Hydraulic motor: MV23 |
| Drive axle: PC-15 | Breaking hammer: GT90 |
| Dimensions: 6600*1300*1950 | Working oil pressure: 140-180bar |
