Main Technical Parameters
| Motor: DEUTZ BF4M1013EC/115kw | Torque Converter: C270 |
| Transmission System: R32000 | Drive Axle Type: Dp81 |
| Braking System: Braking mode | Power: 115KW/2300r/min |
| Bucket Capacity: 6m3 / 12T | Min. Ground Clearance: 250mm |
| Operating Weight: 13T | Climbing Ability: 25° |
| Max. Dumping angle: 65° | Running speed: 0-24.9km/h |
| Front axle oscillating Angle: ±7° | Dimensions: 7366*1900*2300 |
| Min Turning Radius: Inner 4550mm / Outer 7000mm | |
| Max. Disassembly dimension and weight: 3801*1900*1390mm / 7T | |
Features:
1.The key components of this machine adopt international famous brand product. The engine adopts German DEUTZ BF4M1013 which is inter-cooled booster with characteristics of economic, large power, low noise and low emission
2.Adopts the ACME purifier produced by War-industry enterprises, reducing the air pollution and improve the underground working environment effectively.
3.Torque converter and transmission adopt American famous brand DANA, to increase the reliability of the whole machine, the structure components are made of high-strength and low-alloy steel plate with high strength and small deformation. Most components of the torque converter, transmission, drive axle and hydraulic pressure system can realize the general use or exchange with the FCYJ-1.5D underground scooptram produced by our company.
