NFC Sticker
2016-10-06 13:01  Views:133
Price:0.10 USD/Pieces
Brand:HAOBOLAI
Model:-
MOQ:1000 Pieces
Send Inquiry

NFC Sticker

NFC (Near Field Communication) sticker is a standards-based,

proximity contactless connectivity technology that enables simple

and safe two way interactions between electronic devices,

allowing consumers to perform contactless transactions, access digital content,

and connect electronic devices with a single approach.

With the innovative design in its size, it is thin and flexible which makes it

easily to attach to any mobile devices.

The NFC sticker is integrated with RFID chip conforming with ISO14443 which

provides high security. Apart from RFID technology, this sticker can be used

also for payment applications.



IC feature

- IC manufacturer: NXP founded by Philips,Fudan
- Wafer die: MF S50/S70/Ultralight/Ultralight C/Desfire EV1,etc
- Function: Read/Write protect by password
- Frequency: 13.56MHz
- RF protocol: ISO 14443A
- Modulation: ASK

Key Feature

- Operating Frequency:HF 13.56MHz
- Standard:ISO14443A
- Dimension: 29mmx29mm, 45mmx22mm with ferrite layer,or Customerize
- Thickness:0.5mm to 1.0mm with anti metal layer ;0.3mm
- 0.5mm without anti metal layer
- Finish: Glossy, Matte
- Bonding: FLIP chip
- Read range :15mm
- 50mm,depand on the reader and tag antenna size.
- metal Environment(Optional):Enable working directly adhesive on metal surface or Environment
- Working temperature:-25℃ ~ +55℃ – Store temperature:-25℃ ~ +65℃

Printing Option

- Offset Printing – Silkscreen Printing

Additional crafts

- Laser Engrave serial number/UID

Application

- Mobile phones
- Turnstiles
- Vender
- Loyalty system for promotion
- Parking meters


- e-Payment
