Item

Unit

Value

Test Method

base Fabric

Denier

200DX300D

(Domestic yarn)

100%PES

Construction

Weaving/inch

18x12

/

Weight of fabric

Gsm/m2

42±5

DIN53352 BS3424

Method5B

Weight of PVC

Gsm/m2

258±5

DIN53352 BS3424

Method5B

Total weight

Gsm/m2

300±10

DIN53352 BS3424

Method5A

Thickness

mm

0.28±0.02

DIN EN ISO 2286-3

Width

cm

102---320

/

Tensile Strength

N/5cm

Warp

495

DIN53352 BS3424

Weft

300

Tearing Strength

N

Warp

85

DIN53356 BS3424

Weft

65

Adhesion

N/5CM

60

DIN53357 BS3425

Method9B

Temperature Resistance

°C

-20~70

DIN53357 BS3425

Method10

Lacquering

None

Flammability

We can reach: B2, DIN75200.

LOW CADMIUM & HEAVY metaLS

We can reach: EN71-3

Conclusions and

Announcements

Declaration: Please choose products suitably according to relative provisions or industrial standards. The company bears the responsibility for the specified technical and performance data on this page only. The company is not responsible for any other liability. (The technical data on this page is calculated on average, and ±5% tolerance is acceptable)

Remarks : ‘G’represents Glossy surface, “M” represents Matte surface, Glossy or Matte could be made as requirements
