Specifications

Data

Units

Thickness

0.3 ~ 1.5

mm

Width

300 ~ 900

mm

Density

0.91 ~ 1.10

g/cm³

Impact Strength

≥ 33

mpa

Vicat Softening Temp

≥ 150

°С

Tensile elongation at break

50

%

Tensile yield strength

≥ 18

mpa

Surface Resistivity

103 ~ 107

Ω

Flammability Rating

UL94

H-B

Customized Color

Natural color, Black, White, Any other customized colors

Feature

Conductive (103-105Ω)  and Semi-conductive ( 106-107Ω)

(1)  It’s basically not influenced by the temperature and relative humidity. It is laminated by nano-sized & base materials and its surface is super clear.

(2)  We can do conductive function by cutting-edge embedded and coated (oily or water-based) technique to get perfect uniform conductive effect on every inch of PP sheet or roll.

(3)  High mechanical strength, low density, good electrical insulation, good barrier property, good heat resistance, good at high temperature.

Material: 100% virgin raw materials of Polypropylene resin in particles.
