Sensor

1.0MP 720P IP Camera Resolution:1280*720

TV System

NTSC/PAL

Effective Pixels

NTSC: 976(H)x494(V) & PAL:976(H)x582(V)

Resolution

Scanning System

2:1 Interlace

IR LED

Minimum Illumination

IR on 0.001 Lux

Infrared Illumination

Visible up to 15m

Infrared Wave Length

850nm

S/N Ratio

More than 50dB (AGC off )

Gamma

0.45

Auto Gain Control

Built-in

Fixed Lens

8mm lens(2.8mm/3.6mm/4mm/6mm/8mm/12mm/16mm optional)

Operating Temperature

-20C ~50C / -5F ~ 120F

Power

12V DC

Video Out

1.0V p-p 75O, BNC Connector

Auto Iris

Video / DC

Back Light Compensation

OFF/ON/BLC/ HLC

Picture Adjust

Mirror/Brightness/Contrast/Sharpness/Hue/Gain

ATR

ON/OFF

Shutter/ AGC

Auto/Manual

Exposure

Auto

Motion Detection

OFF/ON (Detect sense/ Area Select)

Day / Night

True Day and Night (Auto/ Day / Night / Ext.)S
