60 Long span shelving can be decked with particle board, wire decking, Zinc steel panel, rolling metal decking to make them ideal for many different environments.
60 longspan shelving incorporated a wide range of beams, making it easy to customize to meet your precise demands. Integer J Beam, P Beam can be combined in the same unit for efficient storage of a wide range of stock items. A number of high-performance accessories are also be available to extend the versatility of the Jracking Longspan Systems.

60 Longspan Shelving can be decked with particle board, wire decking, Zinc steel panel, rolling metal decking, making them ideal for any loading ecvironments.

Versatility and flexibility to meet any storage needs:

1. Heights from 1500 mm to 6000 mm

2. frame widths from 400 mm to 1200 mm

3. Shelf loading capacity from 250 to 2000 Kg per level

4. Maximum load per bay up to 5000 Kg

5. Uprights available in Φ1.5 to 2.0 mm steel

6. Choice of steel or timber shelves (for steel, powder-coating or zinc)

Features

•  The most commonly used, of all storage systems for palletised goods. Low capital cost. Easy installation and simple to adjust.
•  Compatible with most types of handling equipment.
•  Less storage density compared to other pallet racking systems

Beam

•  High load capacity up to 2000kg.
•  Manufactured with the highest quality steel.
•  Orange epoxy coated (RAL 2004).
•  Lengths available: 900/1200/1500/1800/2100/2400/2700mm
•  Boltless connection with 3 or 4 connector hooks.
•  A security pins per beam to prevent accidental dislodgement.

·         Surface treatment: powder painting

frame

• High load capacity up to 5000kg.
• frames include all the elements needed for assembly: bracing, feet and nuts & bolts
• Blue epoxy coated (RAL 5017).
• Standard heights : From1.5-6.0m
• Adjusted by 50mm pitch.
