Product name: Flap gate

Model: RS888

The flap barrier possesses superiority over the traditional management mode.

Whether on the control of rights of passenger,tolling, attendance or counting,

traditional management mode requires a great deal of man power and material. Speed gate overcomes such inefficiency and greatly ease off the work to manage high flow of human traffic.The flap barrier features great ascetic looks, stainless finish and durable.

The system is provided with a standard electric interface and is easily integrated with various forms of access control. Special control system is equipped in the product to meet the requirement of fire control, so that the smooth passage flow is ensured, realizing a timely diverting of passengers.

Specification

• Casing size: 1500*300*1000（MM）

• Wing length： 380mm

• Max lane width：900mm

• Weight： 140Kg

• Casing material： SS (304#)

• Power voltage： AC220±10% V,50HZ

• Drive motor： DC brush motor（24V)

• Communication interface： RS485 ( standard)

• Transit speed ：30-40 people/minute

• Close and open time：0.6s

  Features

• One direction or bi-directional control

• Can be integrated with most access control system

• Flow direction guide

• Anti-punch

• Anti-panic

• Normal close or normal open

• Passable on power failure

• Five pcs sensors on each casing

• The lane is open for pass when authorized card is read

• Close and open by remote control

• Soft wing

Applications: subway, handicapped passageway, residential community, lobby, school , factory and so on.
