Brand:ZY
Model:MFZ/ABC1
MOQ:1000 Pieces
Send Inquiry
1kg ABC dry powder fire extinguisher cylinder
1.Material of Cylinder:Carton steel
2.Model of Cylinder
1) ABC dry powder:0.5kg-12kg, 25kg, 35kg, 50kg
2) CO2:2kg, 3kg, 5kg, 6kg, 7kg, 24kg
3) Suspended type:4.5kg, 6kg, 8kg, 10kg, 12kg
3. Followed is the specification of some types.
| ABC POWDER FIRE EXTINGUISHER CYLINDER SPECIFICATION | ||||||||
| ABC Dry powder fire extinguisher | 0.5KG | 1KG | 2KG | 3KG | 4KG | 5KG | 6KG | 9KG |
| OUT-DIAMETER | 70mm | 90mm | 110mm | 130mm | 130mm | 150mm | 163mm | 183mm |
| VOLUME | 0.65 | 1.25L | 2.5L | 3.6L | 4.71L | 6.25L | 7.25L | 11.25L |
| CLINDER LENGTH | 217mm | 240mm | 292mm | 330mm | 397mm | 405mm | 420mm | 494mm |
| POWDER FILLED WEIGHT | 0.5 | 1kg | 2kg | 3kg | 4kg | 5kg | 6kg | 9kg |
| MATERIAL | ST14 | ST14 | ST14 | ST14 | ST14 | ST14 | ST14 | ST14 |
