Brand:HY
Model:HY
MOQ:10 Square Met
Send Inquiry
Galvanized gabion stone cage
Wire:2.0-4.0mm
Hole:8x10,10x12,12x15cm
Zinc coat:40-290g/m
Surface:galvanized,PVC
Specification
1.Material:hot-dipped galvanized / pvc-coated/ galfan
Diaphragm: every 1meter
Dimension length:1-4m width:1m height:0.3/0.5/1m
2.Specification:
| Opening | Wire Diameter(metal Wire) (mm) | Wire Diameter (PVC Coate)/ Inner/Outside(mm) | Strands |
| 60x80 | φ2.0-2.8 | φ2.0/3.0-2.5/3.5 | 3 |
| 80x100 | φ2.0-3.2 | φ2.0/3.0-2.8/3.8 | 3 |
| 80x120 | φ2.0-3.2 | φ2.0/3.0-2.8/3.8 | 3 |
| 100x120 | φ2.0-3.4 | φ2.0/3.0-2.8/3.8 | 3 |
| 100x150 | φ2.0-3.4 | φ2.0/3.0-2.8/3.8 | 3 |
| 120x150 | φ2.0-4.0 | φ2.0/3.0-3.0/4.0 | 3 Contact Infomation
