Brand:vstarcam
Model:H7801W
MOQ:10 Pieces
Send Inquiry
| Model No.：H7801W | ||
| Features | System security | Supports there-level account, password, user multi-level authority management |
| DDNS（free） | Built in free DDNS system,like http://demo.ipcam.so,'demo' is serial code | |
| Super- Client（free) | 1,4,9,16,25,36, 64-channel , no user limited , centralized monitor, remote record and playback , Skype message alarm, skype telephone alarm | |
| IE multi-channel view client(free) | No need to install software, support multi-channel monitor &management & check alarm picture via IE | |
| Superiority | Support monitor via computer and most of intelligent cellphone on the market(such as Android ,sambian,Iphone cellphone) | |
| Local memory | Support up to 32G SD card memory( SD card is not included) | |
| CPU | Operation system | Embedded Linux OS |
| Video | Compression format | H.264 main profile level 3,dual stream |
| Signal system | PAL or NTSC | |
| Sensor | 1/3 SONY CCD | |
| Horizontal resolution | 420TVL | |
| frame rate | Main stream:1-25fps second stream:1-25fps | |
| Resolution | Main stream: D1, CIF, QCIF Second stream:CIF, QCIF | |
| Video adjustment | Brightness, contrast, saturation. | |
| Minimum illumination | 0.5LUX/F1.2 | |
| S/N ratio | ≥48dB | |
| WB, BLC | Auto | |
| Lens | Standard: 6mm CS interface | |
| Audio | Compression format | G.726/G.711 |
| Input | one channel linear output/mircrophone input | |
| Output | one channel linear output | |
| P/T | P/T | one-channel RS485 |
| P/T protocol | PELCO-D protocol baud rate: 9600 address: 1 | |
| Network | Network interface | RJ-45 10/100Mb self-adaptable Ethernet slot |
| Delay time | < 500 MSEL(0.50 second) in LAN | |
| Protocol | TCP/IP，HTTP，TCP，ICMP，UDP，ARP, IGMP，SMTP，FTP，DHCP，DNS，DDNS，NTP，UPNP，RTSP etc. | |
| online visitor | Support 10 visitors at the same time | |
| IP mode | Dynamic IP address, static IP address, PPPOE | |
| Wireless | Support WIFI 802.11b/g | |
| Others | Material | Aluminum alloy material |
| Use environment | Indoor use | |
| Power | DC12V 2A | |
| Temperature | -10~50 °C | |
| Humidity | 95% RH | |
| Size | Item size:165 x 69 x 57 mm (LxWxH）Package size: 217 x 175 x 91mm (LxWxH) | |
| Weight | G.W.: 890g （Note:for real products ) | |
| Accessories | Power adapter,CD,manual,warranty card,bracket,srews | |
| Motion detection regions | support 4 Motion detection regions | |
| Alarm action | Support Email photo, FTP photo, FTP video, message,etc. | |
| System | System requirement | Microsoft Win98 SE/ME/2000/XP,Vista Internet Explorer 5.0, NET4.5 or above |
| Certification | Certificate | ISO FCC CE |
