Brand:vstarcam
Model:f6812
MOQ:10 Pieces
Send Inquiry
| Model：F6812 | ||
| Catalogue | Type | Parameters |
| Features | View by phone | Support monitoring via mobile devices on line(such as iOS、Android OS、Symbian OS、WindowsPhone7) |
| Mobile Platform | No need to install software, Multi-screen monitoring and managing by mobile phone,alarming,viewing. | |
| View on PC | Internet Explorer 6.0 or higher version，firefox，chrome | |
| Super Client | 1,4,9,16,25,36, 64,81-channel , no user limited , centralized monitor, remote record and playback , Skype message alarm, skype telephone alarm | |
| System | Operation system | Embedded Linux OS |
| System security | Supports three-level account, password, user multi-level authority management | |
| DDNS | Provide DDNS for free ,like demo.gocam.so | |
| Collection | Image sensor | 1/4 inch 0.3MegaPixel Color CMOS Image Sensor |
| SNR | ≥45dB | |
| Minimum Illumination | 0.3Lux | |
| 3A | Auto White Balance,Auto Exposure,Automatic Gain | |
| Lens | Standard：6mm | |
| Video | Compression Format | Motion-JPEG |
| Resolution of Main Stream | VGA（640×480）/QVGA(320×240) | |
| Maximum frame rate | 25fps | |
| Bit Rate | 32Kbps～4Mbps | |
| Adjustment | light intensity,contrast ratio,saturation level are adjustable. | |
| Nightvision | Effects | 24 Φ 5 IR leds , IR Distance: 20m |
| Audio | Encode formats | ADPCM |
| Input | one channel linear input /Microphone Input,normal connector Of 3.5mm | |
| Output | one channel linear output,normal connector Of 3.5mm | |
| Network | Socket | RJ-45 10/100Mb self-adaptable Ethernet slot |
| Protocol | TCP/IP，HTTP，TCP，ICMP，UDP，ARP, IGMP，SMTP，FTP，DHCP，DNS，DDNS，NTP，UPnP，RTSP，PPPoE ,etc | |
| Visitors Online | Support 4 visitors viewing on line at the same time | |
| Alarm | Alarm Detection | Support motion detecting / 1 way input triggered |
| Alarm action | 1 way output/E-mail pictures /upload video by FTP/capture and take video by SD card /messages alarm（coordinate to server) | |
| Physical index | Power | DC 12V |
| Comsumption | <6W | |
| Temperature | -10~50℃ | |
| Humidity | 10%~85% | |
| Weight | Net： 625g , Gross: 1100g ( Note: in kind prevail） | |
| Body Size | 175mm x 74mm x 84mm | |
| Package size | 278mm x 196mm x 106mm |
