Main Technical parameter:

1)    Output: 120kg/h

2)    Diameter of thorn roller: Ø250 mm

3)    The speed of rotating of thorn roller: the first 1900round/min

The second, the third 2000round/min, the forth 2100round/min

4)    Dust basket: diameter: 500mm, mesh: Ø2

5)    Motor:    Y132S-4, 5.5KW，four sets

6)    Thorn bar size: 1.09×75°×7 teeth/25.4 mm

7)    Axletree:    thorn roller         1308K             4pcs

            Dust basket 6205-2RS     8pcs    6206-2RS   8pcs

            Interpose chain wheel      6005-2RS        4pcs

            Tighten chain wheel        6205-2RS        2pcs

8)    The size of host machine (length*width*height):  4500×1720×1160 mm

9)    The weight of whole machine: ≈2200kg

 It is mainly used to recycling waste cotton efficiently, with function of dust removing and health keeping.
