Brand:ZN
Model:IIJ-II Series
MOQ:1 Sets
This equipment meets IEC-156, IS6792, ASTM D 877, ASTM D 1816, UNE 21, specially used for testing the dielectric strength of transformer oil.
We have more than 10 years experience, We are not satisfied until
our customers are satisfied!
Application:
IIJ-II automatic tester is designed to test dielectric strength of insulating oil. Adopt industrial single Plate integrated circuit, new model I/O connection, with unique inspection and anti-jamming technology which largely improve its reliability & functionality.
Features:
1. Simple operation, automatically (can be finished just press on key).
2. Menu controlled. Input data is clear.
3. Can store 99 groups of oil testing data, which is convenient to reading and print. The testing data can keep 10 years under the condition of power off.
4. System time can go on running under power off; (The system time is just for reference which can not be the standard of timing).
5. High capacity of anti-jamming, high precision of testing.
6. Small volume, light, which can be operated in the open air very conveniently.
Technical data:
1. Power supply: AC220V ± 10%, 50HZ
2. Output voltage: 80KV, 100KV
3. Capacity: 1.6KVA, 2.0KVA
4. Pressure increase speed : about 2 kva/s
5. Pressure testing speed: 3%
6. Dielectric strength sensitivity : <2KV
7. Wave form distortion : ≤3%
8. Time of dielectric strength: ≤10ms
9. Polar distance:2.5mm
10. Operational environment: Temperature:
11. Storage environment : Temperature:
12. Working altitude: <
13. Packing: Wooden Case
Our Services:
1. High quality products at competitive price
2. 2 years gurantee for all our oil purifiers
3. Engineers available for oversea trainning and installation
4. Life-long technology support freely
On-Line Particles Counter is available,
Oil Moisture Sensor is available,
online Oil Particle Moisture Counter is available
