HS Code:8418699090
Twin-screw / single screw plastic extruder matching with BUSCH box type industrial cooling water chiller
Model:BBP-30DA
Cooling capacity:82.2 kW / 23.4 RT
Whole unit power input:28.6 kW
Whole unit current power:52.3 A
Compressor type:Fully enclosed scroll compressor
Compressor quantity:2 set
Condenser fan power input:1.50 kW
Condenser fan current power:3.84 A
Chilled water flow: 235L/min
Chilled water tube diameter:DN 50
Chilled water pump input power:2.20 kW
Chilled water pump lift head:22 mH2O
Water Tank: 360L
Size:2200mm*1250mm*1850mm
Weight:1250 kg
Power standard:380V/415V/440V/-3P-50Hz/60Hz
Refrigerant:R22/R407C/R134a
Non-standard product and design:Acceptable


Box-type industrial chillers are the units of which applicable cooling(heating) medium is air or water in summer(winter), and their secondary refrigerant is water. They are widely used in various equipments and cooling models of plastics, electronics , food , pharmaceutical , electroplating , chemical , printing , coating , laser and CD-ROMs and other industrial.
