12mmx1250mm levelling machine
1. Brief introduction:
A. Simple structure and beautiful outlook;
B. Easy to setting and operation
C. Little noise and high working efficiency.
2. Main technology parameter:
1. Thickness of leveling: 8mm-12mm
2. Width of material: 1300mm
3. Working speed: 30m/min
4. Roll station: 13 stations(6 for up. 7 for down)
5. The feeding rollers at can be changed from left and right
6. Material of roller: 45# forge steel, HRC48-52.
7. Material of main shaft: 45forge steel 180mm, the surface of the rollers are treated to black.
8. One line for feeding, and one line for service material.
9. Main power(  AC): 90kw (40.9HP, speed: 960r/min; 125RBM)
10. Size of machine: 3000mmx3000mmx1200mm
11. Way of drive: By gear wheel
12. Transimission: Gearbox. (120x500mm) {1: 25}
13. Small moter (2PCS): 2.2kw/PCS=3HP
14. Specification of bearing for rollers (44PCS): SKF company
