High Impact Nylon Housing
Precision metal reflectors
Borosilicate hardened glass lens
Dust and water resistance (gaskets and seals)

Dimensions:
Lens - 5.5"
Size: 140*140*190mm(Width*Height*Depth)
Light fixture - 9 inches tall with mounting bracket - 7.3 inches deep
Weight - 4.2 pounds

Bulb/Ballast Specifications:
35/55 watt HID Xenon H1 6000K type Lamp
35/55 watt internal HID ballast - instant on, 3 seconds to full visible power
Lumen Output - 4500 lumen +/- 400 lumen
HID color temperature 6000K (bright white)

Voltage / Amperage Specifications
On 12 Volts DC - 13 amps start load on 12 Volts DC - 4.2 amps average draw after 60 seconds
On 24 volts DC - 6.5 amps start load on 24 Volts DC - 2.1 amps average draw after 60 seconds
Same unit works on 12 Volts DC and 24 Volts DC - senses voltage and adapts

Waterproof / Vibration Specifications:
IP rating: IP 67
Vibration tolerance: 12G RMS (dual bushing mounting system contains 8 bushings to minimize beam bounce and damage to light)

Mounting:
This HID equipment light is mounted via a 3/8 inch stud. The bracket is adjustable and the operator simply drills a hole in the mounting surface and passes the bolt through that hole. The angle of the light is set and that bolt is tightened to secure the angle.

Operating temperature:
-40 degrees º C to 105 º C

Beam Options:
Flood configuration - covers and area 400 feet long and 400 feet wide
