Play Detector SFTJX is designed to check quickly and efficiently most steering and suspension components without the help of a second person. Drive front or rear wheels onto the moving plate. The play in the components is visually checked with the low-voltage control lamp. Two switches on the lamp control the movements of the plates forward, backward, left and right side. Easily operate to test wear and tear in ball joints, bushings, fixations, pivot points, link bolts and shock absorber mountings.

Feature
Double moving plate can be moved to four directions.
Moving speed can be adjusted.
There is oil box cleaning device in hydraulic system.

Parameter
Max axle load: 3T
Track: 1150--2250 mm
Max. Displacement of moving plate: 100mm
Speed of moving plate: 0.4--75mm/s Can be adjusted
Moving plate size: 750*850mm
Max. Sliding force of one moving plate: 35kN
Motor: 2.2kW
