Designed to check quickly and efficiently most steering and suspension components.
Drive front or rear wheels onto the moving plate. The play in the components is visually checked with the low-voltage control lamp. Two switches on the lamp control the movements of the plates forward, backward, left and right side. Easily operate to test wear and tear in ball joints, bushings, fixations, pivot points, link bolts and shock absorber mountings.

Double moving plate can be moved to four directions.
Moving speed can be adjusted.
There is oil box cleaning device in hydraulic system

Parameter:
Max axle load 10T
Track 1150--2250 mm
Max. Displacement of moving plate ± 50mm(100mm)
Speed of moving plate 0.4--75mm/s Can be adjusted
Moving plate size 750*850mm
Max. Sliding force of one moving plate 35kN
Motor 2.2kW
