Track Roller Bearings

2016-10-22 13:56 Views:294

Price:Negotiable

We supply many kinds of track roller bearings, the models that we can manufacture include KR...PP, KRV...PP, NUTR, NUKR, NUKRE, RNA22...2RS, NA22...2RS, NA22...2RSX, SRO, RSTO, STO...X, NATR, NATV, NATV...PP etc.

Besides normal track roller bearings, we also accept other non-standard track roller bearings, therefore, should be any specific products needed in your market, please do not hesitate to contact us with your detailed requirements.

OD	Bearing Designaiton and Mass				Dimensions						Basic Load Rating				Limiting Speed
	Without IR	Mass	With IR	Mass	D	d	F Fw	B	C	D1	Dynamic	Static	For support roller bearings		Grease
		Mass		Mass	D	d	F Fw	B	C	D1	Dynamic	Static	Cw	Cor	Grease
(mm)		(g)		(g)	(mm)						(N)				(rpm)
19	RNA22/6.2RS	18	NA22/6.2RS	22	19	6	10	12	11.8	16	5000	4350	3050	3000	18000
19	RNA22/6.2RSX	18	NA22/6.2RSX	22	19	6	10	12	11.8	16	5000	4350	3900	3700	18000
24	RNA22/8.2RS	29	NA22/8.2RS	34	24	8	12	12	11.8	18	5500	5200	4800	4800	14000
24	RNA22/8.2RSX	29	NA22/8.2RSX	34	24	8	12	12	11.8	18	5500	5200	4050	4050	14000
30	RNA2200.2RS	52	NA2200.2RS	60	30	10	14	14	13.8	20	7600	8100	7000	8000	11000
30	RNA2200.2RSX	52	NA2200.2RSX	60	30	10	14	14	13.8	20	7600	8100	6500	7050	11000
32	RNA2201.2RS	57	NA2201.2RS	67	32	12	16	14	13.8	22	8500	9700	7500	9000	9500
32	RNA2201.2RSX	57	NA2201.2RSX	67	32	12	16	14	13.8	22	8500	9700	7050	8950	9500
35	RNA2202.2RS	60	NA2202.2RS	75	35	15	20	14	13.8	26	9600	12000	7600	9600	7000
35	RNA2202.2RSX	60	NA2202.2RSX	75	35	15	20	14	13.8	26	9600	12000	7050	9080	7000
40	RNA2203.2RS	94	NA2203.2RS	112	40	17	22	16	15.8	28	12000	16500	9900	13800	6000
40	RNA2203.2RSX	94	NA2203.2RSX	112	40	17	22	16	15.8	28	12000	16500	9090	11800	6000
47	RNA2204.2RS	152	NA2204.2RS	177	47	20	25	18	17.8	33	18500	21900	15200	18300	4600
47	RNA2204.2RSX	152	NA2204.2RSX	177	47	20	25	18	17.8	33	18500	21900	13500	16500	4600
52	RNA2205.2RS	179	NA2205.2RS	209	52	25	30	18	17.8	38	20100	26000	15700	20000	3500
52	RNA2205.2RSX	179	NA2205.2RSX	209	52	25	30	18	17.8	38	20100	26000	13500	18900	3500
62	RNA2206.2RS	284	NA2206.2RS	324	62	30	35	20	19.8	43	23000	28000	18300	25500	2800
62	RNA2206.2RSX	284	NA2206.2RSX	324	62	30	35	20	19.8	43	23000	28000	17500	23500	2800
72	RNA2207.2RS	432	NA2207.2RS	505	72	35	42	23	22.7	50	29800	46300	23000	35500	2200
72	RNA2207.2RSX	432	NA2207.2RSX	505	72	35	42	23	22.7	50	29800	46300	20500	32500	2200
80	RNA2208.2RS	530	NA2208.2RS	628	80	40	48	23	22.7	57	38200	57700	27500	40500	1700
80	RNA2208.2RSX	530	NA2208.2RSX	628	80	40	48	23	22.7	57	38200	57700	25000	38000	1700
85	RNA2209.2RS	545	NA2209.2RS	655	85	45	52	23	22.7	62	40300	63800	28500	43000	1600
85	RNA2209.2RSX	545	NA2209.2RSX	655	85	45	52	23	22.7	62	40300	63800	26000	41000	1600
90	RNA2210.2RS	563	NA2210.2RS	690	90	50	58	23	22.7	68	42100	66000	28000	42500	1300
90	RNA2210.2RSX	563	NA2210.2RSX	690	90	50	58	23	22.7	68	42100	66000	26000	40500	1300

OD	Bearing Designaiton and Mass				Dimensions						Basic Load Rating				Limiting Speed
	Without IR	Mass	With IR	Mass	D	d	F Fw	B	C	D1	Dynamic	Static	For support roller bearings		Grease
		Mass		Mass	D	d	F Fw	B	C	D1	Dynamic	Static	Cw	Cor	Grease
(mm)		(g)		(g)	(mm)						(N)				(rpm)
16	RSTO5TN	8.5	----	----	16	---	7	--	7.8	10	2800	2600	2550	2550	23000
16	RSTO5TNX	8.5	----	---	16	---	7	--	7.8	10	2800	2600	1990	1990	23000
19	RSTO6TN	12.5	STO6TN	17	19	6	10	10	9.8	13	4700	5450	3750	4500	20000
19	RSTO6TNX	12.5	STO6TNX	17	19	6	10	10	9.8	13	4700	5450	3050	4000	20000
24	RSTO8TN	21	STO8TN	26	24	8	12	10	9.8	15	4800	6000	4200	5500	16000
24	RSTO8TNX	21	STO8TNX	26	24	8	12	10	9.8	15	4800	6000	3000	5000	16000
30	RSTO10	42	STO10	49	30	10	14	12	11.8	20	10200	10500	8400	9200	11000
30	RSTO10X	42	STO10X	49	30	10	14	12	11.8	20	10200	10500	8000	8800	11000
32	RSTO12	49	STO12	57	32	12	16	12	11.8	22	11300	12300	8900	10100	9000
32	RSTO12X	49	STO12X	57	32	12	16	12	11.8	22	11300	12300	8500	9600	9000
35	RSTO15	50	STO15	63	35	15	20	12	11.8	26	13200	16000	9100	10700	6500
35	RSTO15X	50	STO15X	63	35	15	20	12	11.8	26	13200	16000	8700	9900	6500
40	RSTO17	88	STO17	107	40	17	22	16	15.8	29	19800	25300	14300	17700	5500
40	RSTO17X	88	STO17X	107	40	17	22	16	15.8	29	19800	25300	12500	15700	5500
47	RSTO20	130	STO20	152	47	20	25	16	15.8	32	20800	27800	16200	21500	4700
47	RSTO20X	130	STO20X	152	47	20	25	16	15.8	32	20800	27800	15000	19900	4700
52	RSTO25	150	STO25	177	52	25	30	16	15.8	37	23000	33400	16500	22900	3600
52	RSTO25X	150	STO25X	177	52	25	30	16	15.8	37	23000	33400	14000	20900	3600
62	RSTO30	255	STO30	308	62	30	38	20	19.8	46	35200	56700	23300	35000	2500
62	RSTO30X	255	STO30X	308	62	30	38	20	19.8	46	33200	56700	21800	33000	2500
72	RSTO35	375	STO35	441	72	35	42	20	19.8	50	35800	58800	26000	38900	2200
72	RSTO35X	375	STO35X	441	72	35	42	20	19.8	50	35800	58800	24500	38900	2200
80	RSTO40	420	STO40	530	80	40	50	20	19.8	58	35200	61800	24000	39000	1700
80	RSTO40X	420	STO40X	530	80	40	50	20	19.8	58	35200	61800	22500	36500	1700
85	RSTO45	453	STO45	576	85	45	55	20	19.8	63	38900	73900	25500	43000	1500
85	RSTO45X	453	STO45X	576	85	45	55	20	19.8	63	38900	73900	24000	41500	1500
90	RSTO50	481	STO50	617	90	50	60	20	19.8	68	43300	84800	26000	46500	1300
90	RSTO50X	481	STO50X	617	90	50	60	20	19.8	68	43300	84800	22800	44000	1300
