SC200/200 (double cages) construction elevator
Rated loading capacity: 2*2000kg
Rated sling speed: 36m/min
Max attached Height: 200m
Output of electric engine Jc100%: 2*3*11kw
Inner Cage Dimension: 3*1.5*2.5
The SC series of construction elevators are widely used at the sites of industrial and civil construction, bridge construction, underground construction, large chimney construction, ship industry and so on. Being suitable for the vertical transport of materials and people, they can also be used as permanent / semi-permanent electric elevators and in various sites like warehouses and high towers.
This series of construction elevators, which are known for their stable performance, reliable safety, easy transportation and strong adaptability, can enhance work efficiency and reduce workers' labor intensity.
| Parameter | SC100 | SC100/ 100 | SCD200A | SCD200/200A | SC200 | SC200/200 | SC200P | SC200/200P |
| Rated loading capacity (kg) | 1000 | 1000/1000 | 2000 | 2000/2000 | 2000 | 2000/2000 | 2000 | 2000/2000 |
| Rated lifting speed (m/min) | 36 | 36 | 36 | 36 | 36 | 36 | 0-56 | 0-56 |
| Rated passenger number | 12 | 12/12 | 24 | 24/24 | 24 | 24/24 | 24 | 24/24 |
| Engine power | 2*11 | 2*2*11 | 2*11 | 2*2*11 | 3*11 | 2*3*11 | 3*18.5 | 2*3*18.5 |
Cage inner dimension (m) | 3*1.3 *2.5 | 3*1.3 *2.5 | 3*1.3 *2.5 | 3*1.3 *2.5 | 3*1.3 *2.5 | 3*1.3 *2.5 | 3*1.3 *2.5 | 3*1.3 *2.5 |
| Cage weight (kg) | 1400 | 1400 | 1400 | 1400 | 1400 | 1400 | 1400 | 1400 |
| Mast section weight (kg) | 163 | 163 | 163 | 163 | 163 | 163 | 163 | 163 |
| Mast section dimension (mm) | 650*650 *1508 | 650*650 *1508 | 650*650 *1508 | 650*650 *1508 | 650*650 *1508 | 650*650 *1508 | 650*650 *1508 | 650*650 *1508 |
| Counterbalance weight (kg) | 1200 | 1200/1200 | ||||||
| Hanger rated lifting capacity (kg) | 180 | 180 | 180 | 180 | 180 | 180 | 180 | 180 |
| Bottom outline dimension (mm) | 3100*4200 | 3100*4200 | 3100*4200 | 3100*4200 | 3100*4200 | 3100*4200 | 3100*4200 | 3100*4200 |
