Also known as Chicken Netting, made of low carbon Iron Wire, the mesh is firm in structure and has flat surface.

Assortments available:
Hot-dipped galvanized after weaving
Hot-dipped galvanized before weaving
Electro galvanized after weaving
Electro galvanized before weaving
Hex. Wire mesh
PVC-coated Hex
Wire mesh in normal twist
Hex. Wire mesh in reverse twist

Uses:
The products can be used as fence for poultry, farms, bird cages, tennis court, also used as light reinforcement in splinter proof glass and cement concrete, laying of roads, or used for insulation in cold storage, and other structure. Galvanized hexagonal wire netting
Mesh Min. Gal. V. G/SQ. M Width
Wire Gauge (Diameter) BWG
Inch mm Tolerance(mm)
3/8" 10mm ± 1.0 0.7mm - 145 2' - 1M 27, 26, 25, 24, 23
1/2" 13mm ± 1.5 0.7mm - 95 2' - 2M 25, 24, 23, 22, 21
5/8" 16mm ± 2.0 0.7mm - 70 2' - 2M 27, 26, 25, 24, 23, 22
3/4" 20mm ± 3.0 0.7mm - 55 2' - 2M 25, 24, 23, 22, 21, 20, 19
1" 25mm ± 3.0 0.9mm - 55 1' - 2M 25, 24, 23, 22, 21, 20, 19, 18
1-1/4" 31mm ± 4.0 0.9mm - 40 1' - 2M 23, 22, 21, 20, 19, 18
1-1/2" 40mm ± 5.0 1.0mm - 45 1' - 2M 23, 22, 21, 20, 19, 18
2" 50mm ± 6.0 1.2mm - 40 1' - 2M 23, 22, 21, 20, 19, 18
2-1/2" 65mm ± 7.0 1.0mm - 30 1' - 2M 21, 20, 19, 18
3" 75mm ± 8.0 1.4mm - 30 2' - 2M 20, 19, 18, 17
4" 100mm ± 8.0 1.6mm - 30 2' - 2M 19, 18, 17, 16

Note:
1. ) The above tolerance comply with standard EN10223-2: 1997;
2. ) Minimum Galvanization is only for typical wire diameter as stipulated separately in the column for your reference; Also it is only for hot dipped Galvanized Netting.

PVC Coated Hexagonal Wire Netting
Mesh Wire Gauge (MM) Width
Inch MM - -
1/2" 13mm 0.6mm - 1.0mm 2' - 2M
3/4" 19mm 0.6mm - 1.0mm 2' - 2M
1" 25mm 0.7mm - 1.3mm 1' - 2M
1-1/4" 30mm 0.85mm - 1.3mm 1' - 2M
1-1/2" 40mm 0.85mm - 1.4mm 1' - 2M
2" 50mm 1.0mm - 1.4mm 1' - 2M
Five Star also offer other specifications you need


Note: The thickness of PVC Coating is usually 0.2-0.4mm, others may arranged as per buyers' request;
Package: Normally each roll packed in water proof paper, then in termo foil (Shrinked Plastic);
