The construction elevator is single or double cages;
Each cage has the lifting capacity of two tons materials and 24 passengers;
Lifting height is from 50-150, or higher

Main technical parameters

Name of parameter  Unit  Value
Rating load  kg   2x2000
Number of passenger  persons  2x24
Rating lifting speed  m/min  34
Max. Lifting height  m  150
Motor power  KW  2x3x11
Inner size of the suspended cabin  m  3x1.3x2.4
Weight of the suspended cabin  kg  1742
Standard section weight  kg  140
Size and material of standard section  mm  650x650-1508
Model of the tripper    SAJ30-1.2
Rating lift weight of the suspender  kg  180
Weight of the suspender  kg  62
Maximum outer size of the ground cabin  mm  5624x3414
