1. Application: It is suitable for rubber, plastic-insulatedcables, tele-phone cables, control cables.

2. The cable laying-up machine is composed of pay-off, stranding cages, tape lapper, haul-off capstar, take-up with traverser, drives and electrical control console, etc.

3. Main Technical Parameters ITEM/TYPE 630 1000 1250 1600
Inner section(mm) 6-95 6-95 6-95 25-240
Cage revotution(r/min) 35 18.04 7.3-17.3 3.37-7.92
Pithches of stranded wire(mm) 207-2200 269.3-4754.3 269.2-2859.3 485-8212
Pitches of paper lapper(mm) 17.5-182 18-184 18-184 17.7-292
Drawing wheel diameter(mm) 2000 2000 2000 2500
Wire outing speed(m/min) 4.61-28.26 4.61-28.26 4.66-20.78 3.84-27.68
Main motor power(kw) 18.5-22 22-30 22-30 37
