Inside the bag filtration system, the filter bag is supported by an inside metal basket. The incoming fluid is to flow out after filtered by the bag, thus the impurity is intercepted in the filter bag. You can continue to use the filter system after changing the filter bag. It is a trend for the bag filter to replace partly the cartridge filter. The small filter bag can filter large amount of liquid.

SAM Side-line Bag Filter vessel
A SIDE-LINE vessel is a full-featured investment-cast filter vessel. A bead, not sand, blasted finish that makes cleaning easy and a cover that can be easily adapted to different opening directions are among SIDE-LINE's many value added features:

For filter bags sizes 01 and 02;
01 Size - 20, 000 lt per hour flow for Nominal rated bags;
02 Size - 40, 000 lt per hour flow for Nominal rated bags;
Side entry inlet connection;
Available in 304 or 316 stainless steel;
2" ANSI Inlet and Outlet;
Buna NTM seals standard (Viton also available)
Maximum operating pressure of 10 bar (standard model)
Steam jacket (Optional)
