SCF series Swing Bolt Closure Cartridge Filter Housing
Feature
Swing bolt closure and flange connection design ensures secure sealing, easy for cartridge's change-out; Set bolt closure is also available
Side-exit and bottom-exit types are both available for different piping
Suitable for SOE flat end, SOE fin end and DOE style filter cartridges
Accepts 9 to 22 rounds and 30" 40" cartridges
Specification
Max. Working temperature & pressure:
150 psi (10.3 bar) # 80 Celsius degree
Cartridge: Length ≤ 40" SOE or DOE
Material: SS304, SS316 or SS316L etc,
Connection: NPT or raised flange, JIS, BSP and DIN are also available
Surface treatment: Mechanical polishing, Matt, Sandblasting, electropolishing and so on
Inlet/outlet: 2.5" raised flange (Standard)
Vent/drain: 1/4" / 1/2" NPT
O-ring/gasket: EPDM, Viton, PTFE(Teflon) encapsulated Viton etc.
Concave bottom is available.
