Product Description

These elements are made in various sizes(from 5 to 40 inches long )and in different micron rating from 1 to 150 microns. The typical honeycomb structure of the filter body gives it a considerable capacity for accumulating impurities present in the fluid being filtered. The larger foreign particles are filtered out on the surface, while smaller particles are blocked later in the inner filtering substance.

Features
Exceptionally high structural strength
Fits all standard housings
Low pressure drop, high dirt holding capacity and long service life
Loose outer layer and tight inner layer assures effective depth filtration
Various filter media and cores fit a wide range of applications

Applications

Electronic industry: Pre-filter for ultra pure water etc.
Food & beverage industry: Filter of mineral water wines and fruit juice etc
Medicine industry: Filter of drug liquid, gases etc
Chemical industry: Filter of organic solvent etc
Petroleum industry: Filter for oil-field flooding

Specifications

Material: Polypropylene, Cotton
Core: Polypropylene, Stainless Steel
Micron Retention Rating 1, 5, 10, 20, 30, 50, 75, 100, 150um
Size: 5", 10", 20", 30", 40", 50"
Maximum operation pressure difference: 60'C, 1.8kg/cm2; 20'C, 3.2kg/cm2
Inner diameter: 28 mm, 30mm
Outer diameter: 63 mm, 114mm
Maximum Operating Temperature: 250'F(12o'C)
Applicable pH value: 1-13
Positive direction: 0.42Mpa
Reverse direction: 0.42Mpa
Steam sterilizing at 125 degree: 0.5 h each time
