Videon converter
The RNO1V1A series supports optical transmission of 8-bit PCM coded video and one bi-directional data through one multimode or single mode optical fiber. It is the smallest video with data transmitter/receiver pair among all OT Systems products. The transmitter only occupies limited space for easy installation within most camera housings.
Transmitters of the RNO series are also compatible with receivers of the Rainbow.
Catering to different system configurations.

Features:
Non-compressed 8-bit digital video transmission
No video degradation over max. Operating distance
Signal to noise ratio better than 60 dB
Supports NTSC, PAL&SECAM video systems
Supports bi-directional data
Supports multi-protocol data in RS232, RS422 & RS485(2 or 4-wire)Tri-state formats
External access for data format selection via DIP switches
Laser diode for optical transmission
Optimum sensitivity for power budget concerns

Excellent suppression of EMI & RFI and elimination of ground loop
Adjustment and maintenance free
No setup just plug-and-play
Transient voltage protection on power supply and all signal inputs & outputs
Robust design for harsh environment applications

Compatibility:
RNO1V1A-SMT also with RNO1V1A-SMR
Accessories: FT-PA/5V. 5VDC power adapter included (US, European, UK or Australian, power plug)
Options: ST type connector is standard. For FT type, specify 'F'in the model
RNO type fits within most camera housing

Specifications
Video
No. Of Channels: 1
Bandwidth: 6.5MHz
Format: PAL/NTSC/SECAM
Input/Output: 1.0 Vp-p, 75 ohms
Differential Gain: <1% typical
Differential Phase: <1° Typical
Signal-to-Noise Ratio: >60dB

Data
No. Of Channels: 1
Data Direction: Bi-directional
Data Interface: DIP switch-selectable RS232, RS422, RS485(2 or 4-wire)Tri-state MPD(Manchester, Bi-phase, etc)
Data Rate: 0-256kbps

Connectors
Optical: ST (standard), FC
Video: BNC
data: 7-pin screw terminal
Power: 2-pin screw terminal

Electrical and Mechanical
Power: 5VDC @ 3W
Dimensions (H x W x D): 160 x 125 x30mm
Weight: 0.75kg
LED Indicators: Power, Video, Optical carrier detected, Data Tx & Rx

Environmental
Operating Temp.: -40 to + 75
Storage Temp.: -40 to + 85
Relative Humidity: 0 to 95% non-condensing
MTBF: > 100, 000 hours
