CNC Hydraulic Plate Press Brake MBC13032, CNC Hydraulic Plate Press Brake
1 GENERAL SPECIFICATIONS
MASTEEL MBC/MBHS SERIES CNC PRESS BRAKE provide bending with high precision and speed with the use of modern techniques in the area of electronics, mechanics and hydraulics. We brings not only accuracy and work efficiency but also safety. The precision repeatability to MASTEEL MBC/MBHS SERIES CNC PRESS BRAKE performing is achieved by synchronizing the hydraulic cylinders with the use of advanced proportional valve control. With automatic indexing of the axes at the start of running process, calibration is provided. Data inputs of material thickness, type and length through an user friendly software enables the control to calculate and provide the following standard control features:
Standard KV-2005 CNC control with 320x240 pixels graphic display for MBC series, standard KV-2004 CNC control with 11" TFT screen and interactive 2D graphic editor for MBHS series.

0.0004" high resolution linear scales provide precision dual ram position feedback
Bosch-Rexroth Closed-loop Proportional Hydraulic position control:
Repeatability at ± 0.0004" and parallelism at ± 0.0004"
Y1, Y2 Programmable independently in angle or position
Ram tilt adjustment at± 0.5"
Hydraulically Synchronized ram parallelism control compensates uneven force on the bend by means of hydro-electrical technique
Programmable ram delay control at bending position under adjustable pressure
Servo CNC back gauge with precision ball screw and linear guide way ensures unsurpassed rigidity and high productivity speed
Back gauge position speed at 500 IPM, repeatability at ± 0.001"
Automatic or programmable back gauge retract feature
Auto and programmable pressure control
Programmable ram top stop and slow bending position
Programmable bending speed
Automatic conversion: Inch / mm
Promecam punch clamping system with quick release on braked under less than 320Ton

2 STANDARD COMPONENTS
Standard KV-2005 CNC control with 320x240 pixels graphic display for MBC series, standard KV-2004 CNC control with 11" TFT screen and interactive 2D graphic editor for MBHS series
Original Givi linear encoders
Original Eurotherm servo motor
Original Eurotherm servo driver
Original BOSCH-REXROTH servo hydraulic system
Original Parker oil seal
Original EMB hydraulic fittings
HIWIN ballscrews
HIWIN linear guideway
SIEMENS and SCHNEIDER electrical components
Original BOSCH-REXROTH pump
Original BOSCH-REXROTH filter
Original MASTEEL brand die and punch

Siemens main motor
3 SPECIFICATIONS
Model: MBC/MBHS130T3200mm
Bending force: 1300KN
Usable length: 3200 mm
Distance btwn housings: 2700mm
Max Open Height: 450 mm
Throat Depth: 320 mm
Backgauge with X Axis
Control Range: 600mm
Max Run Speed: 250mm/s
Position Precision: 0.02mm
Repeatability: 0.01mm
Ram With Y1 Y2 Axis
Control Range: 300mm
Position Precision: 0.02mm
Repeatability: 0.01mm
Ram speed
Rapid down speed: 75mm/s
Run speed: 8mm/s
Return speed: 70 mm/s
Dimensions mm: 3600*2200*2500mm
Approx. Weight: 10600kg
