1Type DC is a sprag type freewheel cage without inner or outer races. It's model and construction is followed for, this type provides higher torque and lower noise while fixed convenient.

2It must be installed in a design providing races, bearing support for axial and radial loads, lubrication and sealing.

3The sprag space tolerance must not be exceeded. Inner and outer races must both have a minimum plain width"e", without any recess, to ensure the freewheel functions correctly as shown on following pages.

4We can offer standard inner and outer races, as shown on the following pages.

5Alternatively, races can be made in case hardened steel shafts, or housings, to the specification below.

6Surface hardness of the finished pargt should be HRC 60 to 62° , for a depth of 0.6mm minimum.

7Core hardness to be HRC 35 to 45° . Surface roughness not to exceed 22CLA. Maximum taper between races: 0.007mm for25mm Width.

8. There are various articles in different sizes. Welcome friends all over the world
