400kva Doosan Diesel Generator

Generator Supply Scope:
1. Engine, alternator, radiator, auto control panel.
2. base frame, base fuel tank, Flexible pipes, flange, exhaust silencer.
3. Battery, battery charger, battery wires, internal cables, circuit breaker.
4. Manual books of engine, alternator, genset, control panel, wires diagram.

Engine:

1. Doosan: P158LE/363KW
2. Displacement: 14.8L
3. Cylinder Arrangement: 8V(vertical in line)
4. Fuel consumption: 215g/kw. H
5. Cooling Method: Water-cooled
6. Air intake way: TC
7. Coolant capacity - engine only: 80.5L
8. Governor method: Electrical Governor

Alternator:

1. Bearing: Single
2. Insulation Class: H
3. Phase: 3 Phase 4 wires
4. Protection Degree: IP 23
5. Excitation way: Brushless Excitation
6. Type: Leroy-somer, Stamford, Marathon for your option

Other Accessories Optional:

Silent canopy, movable trailer, ATS, synchronization control system, etc.
