Generator set features
Power range: 150~580kwAlternator: Leroy Somer, Stamford, ENGGAController: GU320
Output Range: 6KW-600KW
Stroke: Four-stroke
Cooling Method: Water cooling
Frequency: 50Hz
Speed: 1500(r/min)
Cylinder Numbers: 4/6/V12
Starting Method: Electric
Governing: Mechanical/ Electric
Aspiration Method: Natural aspirated / Turbocharged/ Turbocharged intercooled
Rated Voltage: 400V/230

Alternator features of Daewoo Generator Set:
Brush-less, 4 poles, rotation magnet
2) IP21-23 (NEMA1) enclosure is standard for all industrial alternators
3) The insulation system is class H
4) Simple installation and maintenance, with easy access to terminals, rotating diodes and coupling bolts
5) Wide range of flange adaptors and single bearing disc coupling
6) Standard 2/3 pitch windings avoid excessive neutral currents
7) Optional accessories available for easy paralleling with mains or other generators
8) AVR auto voltage regulator, auto exciter, auto adjustment

Optional PMG system of Daewoo Generator Set:
Permanent magnet generator (PMG) system provide constant excitation under all condition
Optional accessories available for easy paralleling with mains or other generators
) AVR auto voltage regulator, auto exciter, auto adjustment

Accessories of Daewoo Generator Set:
1) Standard accessories: Common steel frame, circuit breaker, damper, exhaust silencer, flexible pipe, battery and connecting wires, fuel-water separator, operation manual and document
2) Optional accessories: Engine coolant and oil heater, alternator space heater, cooling for heat exchanger, control system with RS232/485, communication interface, battery charger by main supply, daily fuel tank, ATS and paralleling system, soundproof canopy and moving trailer

Standard

GB/T2820GB1105YD/T502ISO8525-3ISO3046ISO8525, American EPA and CARB

Performance features:
Engine and alternator shall be mounted on a same frame steel skid
Built-in damper for anti-vibration
Small size, low weight, easy to operating, installation and maintenance
World most famous brand diesel engine: Korea Doosan Daewoo series engine
World famous brand AC alternator: Stamford, Marathon, Leroy Somer
Advanced and reliable control module: Key start, auto start, remote control by PC with RS232/485
7) Full range protect function and alarm shutdown feature
8) According to professional standard
9) Daewoo P158, P180, P222 series generator sets, power from 300kW / 412KVA to 580kW / 725KVA
