Cummins Diesel Generator Set
2016-10-22 16:44  Views:45
Price:Negotiable
Send Inquiry

Genset Details:
1. Output: 16kw/20KVA to 800kw/1000KVA
2. Type: Open type or Sound proof type
3. Frequency: 50Hz or 60 Hz
4. Voltage: 220/380V or 230/400V
5. Power Factor: 0.8
6. Phase: 3 phase
7. Wire: 4 wires

Engine Features:
1. World most famous brand diesel engine: Dongfeng Cummins and Chongqing Cummins engine
2. Multi-cylinder in-line or veer engine, 4-stroke, direct injection
3. Naturally aspirated, turbocharged, water cooled or turbocharged with air intercooler
4. Machinery or electronic governing
5. Fuel injection pump
6. Electric motor starting system
7. Forged steel crankshaft, cast iron cylinder and replaceable wet type cylinder liner
8. Low discharge, and low fuel consumption
9. Installed conveniently and maintain easily

Alternator Features:
1. World famous brand AC alternator: Leroy Somer, Stamford, Marathon, ENGGA
2. Brushless, 4 poles, rotation magnet
3. IP21-23(NEMA1) enclose is standard for all industrial alternators
4. H class insulation system
5. AVR self-regulated, voltage regulation rate: ≤ ± 1%
6. Simple installation and maintenance with easy access to terminals, rotating diodes and coupling bolts
7. Wide range of flange adaptors and single bearing disc coupling
8. Radio interference restraining accords with the stipulation of VDE0875-N and ISO8528
9. Moisture proof, sand-proof, dustproof, salt-proof and vibration-proof

Soundproof/Silent Box:
1. Excellent ventilation
2. Oil tank mounted on base frame for 12 Hours working
3. Highly Corrosion Resistant construction
4. Excellent Access for Maintenance
5. Security and Safety
6.1m<80DBA / 7m<70DBA

Control Panel:
1. Automatic control panel (AMF), LCD display
2. Four protection systems
3. Emergency stop

Optional:
1. Trailer type
2. Soundproof / water proof
3. ATS (automatic transfer switch)
4. Parallel system
5. Remote system

PMC System:
1. Standard 23 pitch windings avoid excessive neutral current
2. Permanent magnet generator system provides constant excitation under all condition
3. Optional accessories available for easy paralleling with mains or other generators
4. AVR auto voltage regulation, auto exciter, auto adjustment

Our Advantages:
1. Solve your technical problems in 24 hours and provide international warranty service for engines
2. Design the appearance form according to customers' request
3. Polyester varnish for appearance protecting for shining and raining
4. Four hours testing before out factory
5. 1 year/1500 hrs warranty
6. ISO9001 and CE certification

Genset Model Prime Powe Standby Power Engine              Fuel ConsumptionFuel LubricationCylinder No. DisplacementBore X StrokeCompression Rate Engine Oil Capacity Cooling Water CapacityInspirationNet DimensionNet Weight
KWKVAKWKVA(g/kwh) (g/kwh)   (L ) (mm) (L) (L) (kg)
ENC1616201822.54B3.9-G≤ 229143.9102*12016.51118Turbocharged1800*800*1200650
ENC20202524304B3.9-G≤ 229143.9102*12016.51118Turbocharged1800*800*1200700
ENC24243028354BT3.9-G≤ 214143.9102*12016.51118Turbocharged2000*800*1200800
ENC3030383543.54BT3.9-G≤ 214143.9102*12016.51118Turbocharged2000*800*1200800
ENC40405045564BTA3.9-G≤ 2150.9543.92102*12016.51117.9Turbocharged2000*800*1200900
ENC56567064806BT5.9-G≤ 2150.9265.9102*12017.51624.6Turbocharged2200*960*1400950
ENC707088801006BT5.9-G≤ 2150.9265.9102*12017.51624.6Turbocharged2400*960*14001100
ENC8080100851066BT5.9-G≤ 2150.9265.9102*12017.51624.6Turbocharged2400*960*14001200
ENC96961201061336BTA5.9-G2≤ 2150.9665.9102*12017.51626Turbocharged2400*960*14001300
ENC1041081351181486BTAA5.9-G2≤ 2150.9665.9102*12016.51626Turbocharged2400*960*14001450
ENC1201201501321656CTA8.3-G2≤ 2100.8468.3114*13516.52428Turbocharged2600*1060*17001680
ENC1451451811602006CTA8.3-G2≤ 2100.8468.3114*13516.52428Turbocharged2600*1060*17001790
ENC1601602001802256CTAA8.3-G2≤ 2100.8468.3114*135162431Turbocharged2900*1100*18002000
ENC2002002502202756LTAA8.9-G2≤ 2100.8468.3114*135162431Turbocharged2900*1100*18002250
ENC225  180225200250NT855-GA  ≤ 214  0.89614140*15215.0:1  3764Turbocharged3100*1000*16002500
ENC250  200250220275NT855-GA  ≤ 214  0.89614140*15215.0:1  3764Turbocharged3100*1000*16002550
ENC270  216270240300NT855-GA  ≤ 214  0.89614140*15215.0:1  3764Turbocharged3100*1000*16002600
ENC300  240300270337NTA855-G 1A  ≤ 207  0.88614140*15214.5:1  3764Turbocharged3100*1000*16002650
ENC312  250312280350NTA855-G1B  ≤ 210  0.74614140*15214.0:1  3764Turbocharged3100*1000*16002800
ENC350  280350300375NTA855-G 2A  ≤ 208  1614140*15214.0:1  3764Turbocharged3100*1000*16002850
ENC375  300375320400NTAA855-G7  ≤ 206  0.7614140*15214.0:1  3764Turbocharged3100*1000*16002950
ENC400  320400350437NTAA855-G 7A≤ 206  0.7614140*15214.0:1  3764Turbocharged3100*1000*16003000
ENC450  360450400500KTA19-G3  ≤ 205  0.96618.9159*15914.5:1  5091Turbocharged3700*1400*20003850
ENC500  400500440550KTA19-G4  ≤ 203  1.02618.9159*15914.5:1  5091Turbocharged3700*1400*20003900
ENC562  450562500625KTAA19-G5  ≤ 204  1.12618.9159*15913.5:1  5091Turbocharged3700*1400*23004200
ENC625  500625560700KTAA19-G 6A  ≤ 206  1.37618.9159*15913.0:1  5091Turbocharged3700*1400*23004250
ENC750  600750660825KTA38-G2  ≤ 214  1.141237.9159*15914.5:1  135308Turbocharged4600*1700*25006800
ENC900  720900780975KTA38-G 2A  ≤ 215  1.081237.8159*15914.5:1  135308Turbocharged4600*1700*25006850
ENC100080010008601075KTA38-G5  ≤ 202  1.071237.8159*15913.9:1  135308Turbocharged4900*1900*2500 7750
