Product description:
Legth*Width*Height(mm) 287*42 *52
Dimension of installation(mm) 45x135(mm)
Weigth of door(kg) 25-180(kg)

Function Delay Action
· Swedish Sveriges Provnings (SP) Approval.
· New Design with Excellence.
· Extrusion Aluminum Body, Highly Precies Closer for High Performance.
· Two Separate Valves give Adjustable Closing and Latching Speed
· Standard Back-Check Function, Delay Action is Optional.

Features:
· Easy to Adjust The Speed, All Speed Screws on the Font Side of Door Closer.
· Adjustable Closing Force (EN1-4&EN2-6), Closing & Latching Speed are Adjustable to Meet the High Standard Demand.
· Hight quality Hydraulic Fluid Provide Good Performance for Wide Range of Temperature (-40º C to 40º C)
· Tri-packing for Regular, Top Jamb & Parallel Arm Installation.
· Heavy Duty Rack and Pionion, High Strength Extrusion Aluminum Body with Needle Bearing for Highest Quality.
· Available in Silver(Alum), Antique Bronze (Duro) and Glod. Other Color upon Request.
