Model: BM series
Pull: 50-985ml/r
Speed: 95_1700N. M
We are the specialized manufacturer of orbital hydraulic motor. We can provide more than 2000 kinds of motor with different models and technical parameters: The rated displacement from 50mm to 1600CC, Max. Torque from 50N. M to 3300N. M, Max. Output power from 2 KW to 90 KW, which has provided wide choice to meet customer's needs. Meanwhile, Our products manufactured can be completely interchanged with SAUER DANFOSS OMP, OMR, OMH, OMS, OMT AND OMV series
Features
1. Advanced manufacturing devices for the Gerotor gear set, which use low pressure of start-up, provide smooth, reliable operation and high efficiency.
2. Shaft seal can bear high pressure of back and the motor can be used in parallel or in series.
3. Special design in the driver-linker and prolong operation life. 4. Advanced design in disc distribution flow, which can automatically compensate in operating.
5. The output shaft adopts in tapered roller bearings that permit high axial and radial forces. The case can offers capacities of high pressure and high torque in the wide of applications.
6. Various kinds of flange, output shaft and oil port mounting dimension.
| Technical Data of BM1**---** Series Hydraulic Motors | |||||||||
| Type | Displacement cc/r | Rotated Speed RPM | Flow LPM | Torque N.M | Pressure bar | ||||
| Cont. | Int. | Cont. | Int. | Cont. | Int. | Cont. | Int. | ||
| BM1-50 | 50 | 720 | 850 | 40 | 45 | 95 | 110 | 140 | 160 |
| BM1-63 | 63 | 610 | 840 | 45 | 60 | 125 | 140 | 140 | 160 |
| BM1-80 | 80 | 610 | 670 | 55 | 60 | 155 | 175 | 140 | 160 |
| BM1-100 | 100 | 500 | 540 | 55 | 60 | 195 | 215 | 140 | 160 |
| BM1-160 | 160 | 325 | 350 | 55 | 60 | 265 | 290 | 125 | 140 |
| BM1-200 | 200 | 260 | 290 | 55 | 60 | 320 | 350 | 125 | 140 |
| BM1-250 | 250 | 200 | 230 | 55 | 60 | 390 | 400 | 125 | 140 |
| BM1-305 | 305 | 170 | 180 | 55 | 60 | 400 | 495 | 100 | 125 |
| BM1-395 | 395 | 130 | 150 | 55 | 60 | 445 | 495 | 100 | 125 |
| Technical Data of BM3**---**Series Hydraulic Motors | |||||||||
| Type | Displacement cc/r | Rotated Speed RPM | Flow LPM | Torque NM | Pressure bar | ||||
| Cont. | Int. | Cont. | Int. | Cont. | Int. | Cont. | Int. | ||
| BM3-100 | 100 | 500 | 540 | 55 | 60 | 195 | 515 | 140 | 160 |
| BM3-160 | 160 | 325 | 350 | 55 | 60 | 290 | 320 | 140 | 160 |
| BM3-200 | 200 | 260 | 290 | 55 | 60 | 360 | 400 | 140 | 160 |
| BM3-250 | 250 | 200 | 230 | 55 | 60 | 400 | 450 | 125 | 140 |
| BM3-305 | 305 | 170 | 180 | 55 | 60 | 480 | 510 | 125 | 140 |
| BM3-395 | 395 | 130 | 150 | 55 | 60 | 620 | 650 | 125 | 140 |
| Technical Data of BM5**---**Series Hydraulic Motors | |||||||||
| Type | Displacement cc/r | Rotated Speed RPM | Flow LPM | Torque N.M | Pressure bar | ||||
| Cont. | Int. | Cont. | Int. | Cont. | Int. | Cont. | Int. | ||
| BM5-80 | 80 | 800 | 1000 | 75 | 95 | 200 | 310 | 175 | 280 |
| BM5-100 | 100 | 745 | 925 | 75 | 95 | 250 | 400 | 175 | 280 |
| BM5-125 | 125 | 580 | 730 | 75 | 95 | 315 | 505 | 175 | 280 |
| BM5-160 | 160 | 480 | 715 | 75 | 115 | 385 | 541 | 175 | 250 |
| BM5-200 | 200 | 385 | 580 | 75 | 115 | 460 | 635 | 175 | 250 |
| BM5-250 | 250 | 305 | 460 | 75 | 115 | 560 | 765 | 175 | 250 |
| BM5-305 | 305 | 250 | 370 | 75 | 115 | 570 | 810 | 150 | 210 |
| BM5-395 | 395 | 190 | 340 | 75 | 130 | 710 | 895 | 150 | 175 |
| Technical Data of BM6**---**Series Hydraulic Motors | |||||||||
| Type | Displacement (cc/r) | Rotated SPeed RPM | Flow LPM | Torque N.M | Pressure bar | ||||
| Cont. | Int. | Cont. | Int. | Cont. | Int. | Cont. | Int. | ||
| BM6-200 | 200 | 775 | 875 | 150 | 175 | 480 | 770 | 175 | 275 |
| BM6-250 | 250 | 615 | 835 | 150 | 210 | 620 | 980 | 175 | 275 |
| BM6-310 | 310 | 670 | 485 | 150 | 225 | 780 | 1225 | 175 | 275 |
| BM6-390 | 390 | 390 | 570 | 150 | 225 | 970 | 1455 | 175 | 275 |
| BM6-490 | 490 | 310 | 455 | 150 | 225 | 1220 | 1685 | 175 | 240 |
| BM6-630 | 630 | 240 | 355 | 150 | 225 | 1130 | 1130 | 125 | 140 |
| BM6-985 | 985 | 153 | 230 | 150 | 255 | 1685 | 1873 | 125 | 140 |
