OEE supplies power end parts such as Crank shaft, pinion shaft, crosshead, bull bear, pulsation dampener, frame and so on for following triplex mud pumps:
EMSCO: F-500, F-800, F-1000, F-1300, F-1600
NATIonAL OILWELL: : 8-P-80, 9-P-100, 10-P-130, 12-P-160
GARDNER DENVER: PZ-8, PZ-9.
The products quality is in accordance with the stipulation of API (American Petroleum Institute). OEE's high quality products perform excellent under high pressure, high temperature, and corrosion. OEE's product equipments conform to the requirement of API as well, the processing of products is reasonable and effective.
Mud pump pulsation dampener and bladders
Our pulsation dampener and bladders have the following features:
1. Assembled and tested before using on mud pump.
2. Diaphragms are available in various materials to suit application requirement.
3. Single piece forged bodies provide stronger body and smoother inside surface.
4. Large top cover plate allows fast diaphragm replacement without removing the body from unit
5. API standard bottom connection flange with R39 ring-joint gasket.
6. Field replaceable bottom plates eliminate costly shop repairs and down time.
7. Heavy duty cover protects pressure gauge and charge valve from damage.
Crosshead &Crosshead guide of power end of triplex mud pump
The crosshead and crosshead guide are made of ASTM A48-83 meehanite cast iron featured by good abrasion resistance and long service life. Upper and lower guides are used on F-800 and F-1000 mud pumps, so that the concentricity can be adjusted by adding shims beneath the lower guide. F-500 mud pump is the cylindrical structure. Bolted flange is used at the connection between the crosshead and the extension rod. The rigid connection ensures the concentricity of the crosshead and the extension rod.
Pinion shaft of power end parts&components for Triplex mud pump
Pinion shaft is made of forged alloy steel on which a herringbone gear with the medium-hard tooth surface is machined. For easy maintenance, the single row radial long cylindrical roller bearing with inner ring (without sides) is used. Both ends of the pinion shaft extend out, so that the sheave or the sprocket can be mounted on either end.
Crankshaft of power ends for Triplex mud pump
The crankshaft is made of cast alloy steel and is furnished with big geared ring, connecting rod and bearing. The tooth form of the big-geared ring is herringbone gear. The gear bore and the crankshaft surface is interference fitted and they are both fastened with bolts and lock nuts. The big end of the connecting rod is mounted on three eccentric straps of the crankshaft through single row short cylindrical roller bearings and the small end on the crosshead pin through double row long cylindrical roller bearing. Double row radial spherical roller bearings are mounted at both ends of the crankshaft.
We also supply power end parts such as Crank shaft, pinion shaft, crosshead, bull bear, pulsation dampener, frame and so on for following triplex mud pumps:
The products quality is in accordance with the stipulation of API. OEE's high quality products perform excellent under high pressure, high temperature, and corrosion.
If you need any items, kindly let us know, we will give you a satisfied quotation.
